OT-24300-TDWJ

Maximum 300W Class 2 LED driver available with a 24V DC output, engineered to deliver high-capacity, low-voltage power for LED lighting systems while meeting Class 2 safety standards for reliable, efficient, and secure operation across demanding indoor and outdoor applications.

HIGHLIGHTS

  • Passive Cooling: Utilizes free air convection for efficient and silent heat dissipation.
  • High Efficiency: Achieves up to 88% energy efficiency with a minimum load requirement of just 10%.
  • Application Versatility: Ideal for LED lighting and moving sign installations.
  • Protective Housing: Full aluminum enclosure rated for dry and damp location use.
  • Dimming Compatibility: Matches with TRIAC, electronic low voltage (ELV), and magnetic low voltage (MLV) dimmers.
  • PWM Output: Pulse-width modulation ensures stable output without affecting the color index.
  • Flicker-Free Dimming: Compatible with forward phase, reverse phase, TRIAC, MLV, and ELV dimmers for smooth, flicker-free lighting control.
  • Wide Input Range: Supports 110–277V AC input and works with both 120V and 277V dimmers, allowing flicker-free dimming down to 1%.

12V CLASS 2 DRIVER

Specifications
  • Wattage
    300W
  • Power Factor
    0.99 at 120V AC | 0.97 at 277V AC
  • Dimmable
    Yes
  • Input Voltage
    110-277V AC
  • Output Voltage
    24V DC
  • Amps
    12.5A
  • Frequency Range
    47-63Hz
  • AC Current (max.)
    3.4A at 110V AC
  • Short Circuit
    Shut down o/p voltage;
    Repower on to recover after fault condition is removed
  • Over Loading
    120%
  • Efficiency
    88%
  • Withstand Voltage
    I/P-O/P: 1880V AC
  • Isolation Resistance
    I/P-O/P: 100MΩ / 500V DC / +25ºC / 70% RH
  • Operating Humidity
    20-90% RH, non-condensing
  • Operating Temperature
    -40ºC ~ +60ºC
  • Warranty
    5 Years
  • Case Quantities
    10

Certifications

PRODUCT SHEETS

Spec Sheet

OT-24300-TDWJ Spec Sheet

Instruction Manual

OT-24300-TDWJ Instruction Manual

Dimmer List

OT-24300-TDWJ Compatible Dimmer List

IES Files

NA
