1 3

OD-RH320

Powerful 320 CFM 30-inch range hood fan with 3-speed settings, designed to deliver efficient ventilation and reliable performance for modern kitchen environments.

Color: White

HIGHLIGHTS

  • Installation Type: Suitable for outdoor or indoor vented installations (ducted or non-ducted)
  • Performance: Powerful 320 CFM motor with energy-efficient LED lighting
  • Filtration: Includes 2 dishwasher-safe aluminum filters and 1 charcoal filter
  • Electrical Specs: AC 120V, 60Hz power supply
  • Mounting Height: Recommended 18 to 24 inches from cooktop to bottom of hood
  • Grease Filter: Equipped with aluminum grease filter

STRONG AND SILENT

Specifications
  • Voltage
    120V AC/60Hz
  • Air Volume (CFM)
    313.2 CFM (High Speed) | 238 CFM (Mid Speed) | 117.2 CFM (Low Speed)
  • Noise (sones)
    2.1 sones. (Low speed) | 5.1 sones (Medium speed)
 | 7.6 sones (High speed)
  • Control
    3 Speeds Push Buttons
  • Lighting
    2x5W GU10
  • No. of Motor
    Single
  • No. of Speed
    3 speed
  • Filter
    Open Mesh (Qty. 2)
  • Use
    For indoor use only
  • Warranty
    1 year limited warranty on the motor | No warranty on the lights

CERTIFICATIONS

Product features

PRODUCT SHEETS

Spec Sheet

OD-RH320 Spec Sheet

Instruction Manual

OD-RH320 Instruction Manual

Revit Files

NA
