SLIM3-5CCT

3" round LED slim downlight with selectable CCT and interchangeable trims for versatile, low-profile lighting solutions.

HIGHLIGHTS

Optics: Edge-lit technology for no glare, no dark spots, and instant-on performance
Installation: No recessed housing or junction box required
Dimming: TRIAC compatible, dimmable down to 10%
Insulation Rating: I.C. rated for direct contact with insulation (indoor only)
Wet Location: Suitable for wet locations (indoor only)
Longevity: Rated for over 50,000 hours of operation
Cable: FT6 plenum-rated cable included
CCT Options: 5-color field selectable—2700K, 3000K, 3500K, 4000K, 5000K

5CCT Selectable

Specifications

Wattage

6W
Voltage

120V AC
Lumens

500 lmn
Beam Angle

120°
CRI

90Ra+
Air Tight

Yes
Dimmable

Yes (TRIAC dimming)
Lifetime

50,000 hours
Rating

IC Rated | Indoor Location | Suitable for Wet Location (indoor only)
Grade of Protection

IP44
Application

Recessed ceiling / Halls / Home / Office / Store / Cafe
Cutout

Ø3-5/64"(78mm)
Colour Temperature

5CCT [2700K/3000K/3500K/4000K/5000K]
Operating Temperature

-20°C ~ +40°C
Warranty

5 Years
Case Quantities

24

CERTIFICATIONS

Product features

DECORATIVE TRIMS (sold separately)

SLIM3-RINGBK

SLIM3-RINGBK
(Black)

SLIM3-RINGSN

SLIM3-RINGSN
(Satin Nickel)

SLIM3-RINGCH

SLIM3-RINGCH
(Chrome)

SLIM3-RINGVB

SLIM3-RINGVB
(Vintage Brass)

SLIM3-RINGCBK

SLIM3-RINGCBK
(Chrome Black)

ACCESSORIES (sold separately)

PLATE13-3, PLATE13-3-L, PLATE26-3, PALTE26-3-L

PLATE13-3, PLATE13-3-L, PLATE26-3, PALTE26-3-L
(Construction plate made up of galvanized steel for recessed lighting)

PLATE3-HB

PLATE3-HB
(Galvanized steel mounting plate with hanger bars)

CORD-FT6-24/FT6-120

CORD-FT6-24/FT6-120
(Flexible Connector 2FT/10FT)

DMD-ELV

DMD-ELV
(Electronic low voltage dimmer switch with single pole 3 way wiring)

PRODUCT SHEETS

Spec Sheet

SLIM3-5CCT Spec Sheet

Instruction Manual

SLIM3-5CCT Instruction Manual

Dimmer List

SLIM3-5CCT Compatible Dimmer List

IES Files

SLIM3-5CCT IES Files
