PUK M

1W 12V DC Super Slim LED Puk Light for mounting inside cabinet


Available Finishes:
  • White
  • Satin Nickel
  • Black

Description:
  • Inherently protected
  • Must be used only with class 2 power unit
  • 1 x Micro LED light and mounting hardware included
  • Easy installation and suitable for damp location where not exposed to rain or snow



Compatible Drivers (sold separately):

OT-08D OT-15D OT-24D OT-48D OT-60D OT-96
Max. 8W class 2 driver Max.15W class 2 driver Max. 24W class 2 driver Max. 48W class 2 driver Max.60W class 2 driver Max. 96W class 2 driver
Wattage 1W
Voltage 12V DC
Lumens 70 lmn
Beam Angle 60°
Lifetime 50000 hours
CRI 80
Dimmable No
Rating Non-IC Rated / Indoor use / for Damp location
Grade of Protection IP 42
Application Under cabinet / Home / Office / Kitchen / Workshop, etc.
Colour Temperature 3000K (Warm White) / 5000K (Cool White)
Operating Temperature -20°C ~ +40°C
Warranty 5 years
  1. Open packaging and place all components on to a clean surface
  2. Turn power OFF from the electrical panel before starting installation
  3. For recessed mounting — Remove the MicroLED light completely from surface mounting ring.
    Drill a 1-1/8" cut hole using a Forstner Bit (not included) in the desired location.
    Run the wires through the cut hole and attach the MicroLED light flush to medium
  4. For Hardwire — Use wire type and gauge suitable for application to connect the fixtures, and twist-on wire connectors (not included).
    Ensure correct polarity is followed throughout the line
  5. For Plug-in — Make a daisy chain connection with male to female DC 2.1 connectors.
    Attach DC 2.1 connector to a power feed from the 12V constant voltage driver
  6. Rest driver to the desired and secure location
  7. Once assembly is complete, turn on power to confirm fixture is working properly
